DB110-04W 4-Channel Thermocouple Data Logger with Wi-Fi and USB interfaces

Description

Our 4-channel thermocouple data logger uses Wi-Fi & USB to provide high-accuracy measurement of temperature data anywhere within your network area or to a computer. You can use our BadgerView application for viewing and logging data to file, or develop your own program with DataBadger’s powerful API.

• 0.01°C resolution and accuracy of up to ±0.15% (assuming proper thermocouple calibration and stable operating environment)
• 50/60Hz mains frequency filtering
• -210°C to +1800°C measurement temperature, dependent on thermocouple selection
• Cold-junction compensation and thermocouple linearisation
• Four channel thermocouple data (available with K, J, N, R, S, T, E, and B type thermocouple connections) – Matching connector to thermocouple type maximises data accuracy
• Wireless interface allowing access to data from anywhere in the world – requires internet connection and configuration
• Simple and user friendly data logging using the BadgerView application
• 2.4GHz b/g/n Wi-fi, allowing freedom from signal cabling
• USB port for initial configuration of wi-fi network and data access to a PC
• TCP interface makes our loggers ideal for incorporation into IOT and Industry 4.0 manufacturing systems
• Powered by included 5V DC power supply

Does not include thermocouples.

DataBadger can supply thermocouples on request. Please contact us for more information.
